976nm Single Mode Narrow Linewidth Laser Module NLS Series

Name: 976nm Single Mode Narrow Linewidth Laser Module NLS Series
Brand: CRYLINK
Price: 1 USD

China 976nm Single Mode Narrow Linewidth Laser Module NLS Series wholesale

Brand Name : CRYLINK

Model Number : 976nm Single Mode Narrow Linewidth Laser Module of NLS Series

Certification : ISO9001

MOQ : 1

Price : custom

Payment Terms : L/C, D/A, T/T, Western Union, MoneyGram

Contact Now

976nm Single Mode Narrow Linewidth Laser Module of NLS Series

Single mode narrow linewidth laser module is a special product of our company. It is equipped with standard I / O interface, which can be easily embedded into the user’s whole system and realize very stable single mode narrow linewidth laser output. The product has built-in optimized optical feedback power stabilization module and Tec refrigeration module, which makes the product have good spectral characteristics and power stability characteristics. Customized and secondary development services can be provided according to customer requirements.(Download PDF)

Model and Parameter

Model		CL976-ISF(FA)-300mW-NLS002
Optical Parameter	Central Wavelength (nm)	976
	Output Power (mW)	300
	Wavelength Tolerance (nm)	±1
	Line Width (nm)	<0.2
	Wavelength Stability	±0.005nm @8H
	Power Stability	±1.0%@8H
	Side Mode Rejection Ratio (dB)	40
System Parameter	Power Adjustment Range	0～100%
	Preheat Time (min)	15
	Control Interface	PH2.0-10P,USB
	Fiber Interface	FC/APC
	Adaptive Optical Fiber	5µm,0.14NA
	Power Input	4.9V-5.1V @2A
	System Power Consumption (W)	<4
	Storage Temperature (℃)	0～70
	Storage Humidity	0～80%RH
	Operating Temperature (℃)	10～35
	System Weight (g)	150
	Laser Power Size (mm)	76.2ⅹ63.5ⅹ22

Feature

Wavelength stability ± 0.005nm / ℃
High power single mode fiber coupled output
USB settings
Low power consumption, typical power consumption <4W

Application

Confocal microscope
Raman spectrometer
Fluorescence Spectrometer
Up-conversion material
Laser particle size analyzer
